FEA Structural Analysis of Bulkhead

[raza44]

Hi Friends,
I am working on structural analysis of bulkhead design, but getting failed in meshing phase due to the size(6m*8m) and complexity of the structure design. i am open to any sujjestion regarding any technique to get quad meshed element.
currently i am working on ANSYS and ABBAQUS, so if you have any sujjestion you are more than welcome to throw at me.
i am attaching bulkhead design



[IRstuff]

Please refrain from double posting

TTFN (ta ta for now)
